USB SMART charger 2.1A 1M

USB SMART charger 2.1A 1M

5V DC USB charger for mobile phones, smart phones, tablets, MP3 players, portable consoles etc.
Smart identification technology, different charging current for different devices
Charging current up to 2,1A
Power supply 230V~ 50Hz /125mA
Screw contacts 1.5-2.5mm2
Protection degree IP20
Working temperature 0°C- +35°C (indoor use)
Overvoltage category III
In accordance with USB A standard,
Directive 2014/35/EU (LVD) standard EN 62368-1,
Directive 2014/30/EU (EMC) standards EN 61204-3, EN 61000-4-4, EN 61000-4-5, EN 61000-4-2, EN 61000-4-11, EN 61000-6-3
Install the device at a height of no more than 2 m. Cable stripping 6mm.

SAFETY PRECAUTIONS DURING INSTALLATION
Installation and maintenance must be carried out by qualified person and in accordance with current regulations regarding the installation of electrical equipment in the country where the products are installed, otherwise there is a danger of electric shock!
Turn of power before installation or maintenance.
An easily accessible omnipolar disconnection switch with a contact gap of at least 3 mm must be installed upstream from the power supply.

ASSEMBLY INSTRUCTIONS
Install the module support into the mounting box.
Connect the USB charger accroding to wiring diagram and check the connections.
Push the USB charger into the module support.
Finish the assembly by installing the cover plate and only after that turn on the power.
WARNING FOR SAFE USE
Connected devices must not exceed the rated load.
Overload, electric discharges and short cuts may permanently damage the device.
Use the device exclusively in accordance with the stated purpose and
with the original cables from the device.
Use non-standard cables may cause malfunction and device destruction.
Insert USB connector into the charger with correct orientation, straight and without applying force.
Never connect an USB output with other power supplies.
The device clean with a dry cloth. Do not clean with alcohol, oil or solvents.
